YCWQ Series High-Efficiency Permanent Magnet Submersible Sewage Pump

The YCWQ Series High-Efficiency Permanent Magnet Submersible Sewage Pump represents a new generation of ultra-energy-efficient products, officially included in the Nanjing Innovation Promotion Demonstration Product Catalog. The hydraulic components are optimized through CFD (Computational Fluid Dynamics) simulation, delivering high efficiency, anti-clogging, and anti-cavitation performance. The drive system utilizes a high-efficiency permanent magnet motor, featuring high power density, superior efficiency, high power factor, and compact design. Operating under vector frequency control, the unit ensures stable performance and avoids inefficiencies caused by improper model selection, expanding the effective operating range.

• Municipal Engineering, Construction Sites, Civil Defense Systems
• Sewage Treatment Plants, Waterworks
• Exploration, Mining Operations
• Drainage for Roads, Tunnels, Metro Structures, and Building Basements
• Bridge, Tunnel, and Culvert Dewatering
• Basement and Garage Water Discharge
• Agricultural Irrigation
• Emergency Water Intake/Discharge at Water Sources

1、High-Efficiency Permanent Magnet Motor:

• Achieves up to 97% motor efficiency, improving unit efficiency by 3–5% points with motor replacement alone. Short investment payback period.
• Power factor up to 0.99, eliminating capacitor compensation requirements. Compared to traditional three-phase asynchronous motors, it reduces rated current at the same power output.

2、Vector Frequency Control Technology:

• Soft-start with gradual current increase from 0, minimizing grid and equipment stress.
• Maintains high motor efficiency and power factor across variable-speed operations, expanding the efficient working range.

3、Hydraulic Design:

• CFD-optimized hydraulic components ensure high efficiency, anti-clogging, and anti-cavitation performance.

4、Reliability & Safety:

• Insulation Class H: Ensures safe and reliable operation.
• Dual Mechanical Seals: Combined with specialized watertight cable structure, guarantees motor safety underwater. Optional stator encapsulation for customized solutions.
• Integrated Protection Systems: Oil chamber leakage detection, temperature sensors, and anti-condensation devices.

5、Installation & Maintenance:

• Automatic Coupling System: Simplifies installation and servicing.
• Optional Water-Jacketed Cooling System: Ensures reliable operation in sewage (dry-run) conditions.
